[Modern Robotics] 강좌 3: 로봇 동역학 #4









Path $\theta(s)$: a geometric sequence of configuration $\theta$ with respect to a geometric path parameter $s$.

●$s\in[0,1]$. (0-100%)

●Shows how the configuration changes from where it starts, through its intermediate values, and to where it ends.

●e.g. $\theta(s)$ for a revolute joint configuration, $x(s)$ for a task space configuration, etc.





Time scaling $s(t)$: a mapping time $t$ to $s$. A time parameter.

●$t\in[0,T]$. $T$ is the duration.

※$t\in[T_{0}, T_{f}]$ ($T_{0}$: initial time,  $T_{f}$: final time), you can use this $s(t)$ but the time scaling equations in this chapter will need to be modified accordingly.





Trajectory $\theta(s(t))$ or $\theta(t)$: It shows how the configuration $\theta$ changes with respect to time $t$.

●Path + Time scaling → Trajectory

●Dynamically well-defined(that ensure the acceleration) trajectory consist of twice differentiable path($\frac{d^{2} \theta}{ds^2}$) and time scaling($\frac{d^{2} s}{dt^2}$)









Point-to-Point Trajectory

Path

Joint space($\theta$) straight line: $\theta(s)=\theta_{start}+s(\theta_{end}-\theta_{start})$, $s\in[0,1]$

●Joint limit: $\theta_{min}<\theta<\theta_{max}$





Task space($X$) point-to-point:

●There might be unreachable sections on the joint space path due to the inverse kinematics or the joint limits.



For explicit representation $X=[x,y,z,\phi,\theta,\psi]\in\mathbb{R}^{6}$

●$X(s)=X_{start}+s(X_{end}-X_{start})$, $s\in[0,1]$



For implicit representation $X\in SE(3)$, there are two ways ①②.

①Utilize the screw motion

$X(s)=X_{start}T(s)=X_{start}\text{exp}(\text{log}(X_{start,end})s)=X_{start}\text{exp}(\text{log}(X_{start}^{-1}X_{end})s)$,  $s\in[0,1]$

●Though it's a point-to-point path, the origin doesn't follow a straight line since it's the screw motion.



②Decouple position and rotation $X=[p,R]^{T}$, $p=[x,y,z]\in\mathbb{R}^{6}$, $R\in SO(3)$

$p(s)=p_{start}+s(p_{end}-p_{start})$,   $R(s)=R_{start}\text{exp}(\text{log}(R_{start}^{-1}R_{end})s)$,  $s\in[0,1]$

●The origin follows a straight line between the start and end position.









Time scaling

3rd-order polynomial(Cubic spline): define time scaling with start and end position, velocity.

$s(t)=a_0+a_1t+a_2t^2+a_3t^3$



●For $t\in[0,T], s(0)=0, \dot{s}(0)=0, s(T)=1, \dot{s}(T)=0$

$a_0=a_1=0, a_2=\frac{3}{T^2},a_3=-\frac{2}{T^3} $



●For $t\in[t_s,t_e], s(t_s)=0, \dot{s}(t_s)=0, s(t_e)=1, \dot{s}(t_e)=0$

$a_0=a_1=0, a_2=\frac{3}{(t_e-t_s)^2},a_3=-\frac{2}{(t_e-t_s)^3}$





5th-order polynomial(Quintic spline): define time scaling with start and end position, velocity, acceleration.

$s(t)=a_0+a_1t+a_2t^2+a_3t^3+a_4t^4+a_5t^5$



●For $t\in[t_s,t_e], s(t_s)=0, \dot{s}(t_s)=0, \ddot{s}(t_s)=0, s(t_e)=1, \dot{s}(t_e)=0$, \ddot{s}(t_e)=0

$a_0=a_1=0, a_2=0,a_3= \frac{10}{(t_e-t_s)^3} , a_4=-\frac{15}{(t_e-t_s)^4}, a_5=\frac{6}{(t_e-t_s)^5} $



●Smoother motion, a higher maximum velocity than a cubic spline.







Trapezoidal motion (velocity) profile



●Starts with constant acceleration $a$, followed by constant velocity phase, and decelerates with $-a$.

●Generally used for the control of a single motor joint.

●Not as smooth as the cubic spline.

●Given joint velocity and acceleration limits, the trapezoidal motion profile makes the fastest motion respecting the limits.(Using $a=a_{max}, v=v_{max}$)







S-curve time scaling

●Improve the trapezoidal motion profile so as not to have infinite jerk.















Via points Trajectory

●Given $k$ via points(including the start and end points), the trajectory is divided into $k-1$ segments(subtrajecotry).

●Connect each segment using polynomial interpolation.

●The trajectory is ensured to be through the via points.

●Some parts of the trajectory may be out of the convex hull of the via points.



3rd-order polynomial(Cubic spline)

●Each via point has the desired velocity.

●The end position and velocity of a via point will be the start position and velocity of the following via point.

$\theta_{i,e}=\theta_{i+1,s}$, $\dot{\theta}_{i,e}=\dot{\theta}_{i+1,s}$





5th-order polynomial(Quintic spline)

●Each via point has the desired velocity and acceleration.

●The end position, velocity, and acceleration of a via point will be the start position, velocity, and acceleration of the following via point.

$\theta_{i,e}=\theta_{i+1,s}$, $\dot{\theta}_{i,e}=\dot{\theta}_{i+1,s}$, $\ddot{\theta}_{i,e}=\ddot{\theta}_{i+1,s}$





B-spline interpolation

●The trajectory is not ensured to be through the via points.

●The trajectory must be confined to the convex hull of the via points.











========================================================================
